Big Tex Heavy Duty Tandem Axle Seamless I-Beam Equipment Trailer | 14EH

Description It’s time for a trailer that makes the heaviest hauls easier to handle—it’s time for the 16LP Super Duty Ultra Low Profile Dump Trailer. Bringing together a heavy-duty frame and durable construction with an ultra-low profile for easy loading, unloading, and transporting, the 16LP delivers the strength and premium features that construction and landscaping professionals require for their daily grind. And with an integrated frame and tongue, this trailer is a robust, long-lasting that’s ready for the toughest tasks you can throw at it. Standard Feature Available Options Axles 2 – 8,000# Premium, Cambered Axles with Oil Bath and Valcrum Caps Brakes Forward Self-Adjusting Electric Brakes on Both Axles Suspension Multi-Leaf Slipper Spring w/ Equalizer Tongue 8″ Seamless I-Beam Integrated w/ Frame (10#) Coupler 2-5/16″ Ball, Adjustable Demco EZ Latch Coupler Adjustable Pintle in Channel in Lieu of Coupler Safety Chains 3/8″ Grade 70 w/ Safety Latch Hook (2 ea) Jack 12,000# Drop-Leg Jack (Side Wind) 12,000# Elec/Hyd. Jack BY Stillwell™ Frame 8″ Seamless I-Beam (10#) Cross-Members 3″ Channel on 16″ Centers Floor 7 Gauge Smooth Steel Fenders 9″ x 72″ 14 Ga. Diamond Plate Double Broke Ramps Not Included 6.5’ Slide In Ramp Package Stake Pockets Stake Pockets Along Both Sides (Quantity Varies by Length) Trailer Plug 7-Way RV Lights Recessed, Grommet-Mounted L.E.D. Lighting Wiring Sealed, Modular Cold-Weather Wiring Harness Tires ST215/75 R-17.5 Load Range H Radial Tires Bolt Pattern 8-Lug Wheels Black Mod Steel Spare Mount Side Spare Tire Mount Spare Tire Not Included Spare Tire & Wheel (ST215/75 R-16 LR-H) Paint Type Professional Finish w/ Primer Standard Paint Color Black Tie-Downs (4) 1/2″ D-Rings Inside Bed to Secure Equipment Along Sides and Rear for Cargo Control Break-Away Kit Complete Breakaway System w/ Zip Breakaway Cable Battery 12V Deep Cycle Charger 5A 110V on Board Battery Charger Gate Rear Combo Gate (Barn Doors & Spreader Gate) J-Hooks Along sides and rear for Cargo Control Power Power Up/Power Down & Gravity Down Hydraulic Pump 5 Watt Solar Charger Wireless Remote Ram Self-Contained Scissor Sides 24″ Tall (10 Ga) with formed Channel Supports 3′ Solid Sheet Metal Sides 4′ Solid Sheet Metal Sides Stabilizers Rear Stabilizer Stands Steps Convenient Side-Step to Access Top Rail Storage Lockable Pump and Battery Box mounted in Front of Bed Tarp Fully-Formed Tarp Shroud with Tarp & Rear Tarp Rod Holders Top Rail 3″x 2″ Rectangular Tubing Steps & Handles Convenient Side-Step to Access Top Rail Model 16LP-16 16LP-14 Pull Type Bumperpull Bumperpull GVWR 17500 lbs 17500 lbs GAWR (Ea. Axle) 8000 lbs 8000 lbs Empty Weight 4950 lbs 4500 lbs Cargo Capacity 12550 lbs 13000 lbs Bed Length 16′ 14′ Bed Width 83″ 83″ A 192″ 168″ B 115-3/4″ 100″ C 76-1/4″ 68″ Tongue Length 51-1/8″ 51-1/8″
