Big Tex Heavy Duty I-Beam Equipment Trailer | 16EH

Description Facing down heavy-duty, demanding, and challenging loads? Then it’s time to call in the big guns with the 14PI Heavy Duty Tandem Axle Pipe Top Utility Trailer—a heavy-duty pipe-top equipment trailer that’s specifically designed and built to take on the toughest and heaviest loads. Coming standard with an adjustable forged coupler and LED lights, it’s a rugged and durable utility trailer that has the muscle for heavy-duty hauling and transport. And it features a treated floor for a professional-grade appearance that also delivers the brawn. STANDARD FEATURE AVAILABLE OPTIONS Axles 2 – 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs Brakes Forward Self-Adjusting Electric Brakes on All Hubs Suspension Multi-Leaf Spring w/ Equalizer Coupler Adjustable 2-5/16” Demco EZ Latch Adjustable Pintle in Channel Safety Chains 1/4″ Grade 70 w/ Safety Latch Hook (2 ea) Jack 8,000# Drop-Leg Jack (Side Wind) Frame 5″ x 3″ x 5/16″ Angle Cross-Members 3″ Channel on 16″ Centers Floor Treated Pine Floor Blackwood Pro Rubber Infused Lumber Floor (per linear foot)1/8” Diamond Plate Steel Floor (Per Square Foot) Fenders 9″ x 72″ 14 Ga. Diamond Plate Double Broke Ramps 4′ Slide in Channel Ramps 4′ Heavy Duty Integrated Ramp Gate w/ Gas Shock Assist5’ Stand Up Ramps 5’ Heavy Duty Integrated Ramp Gate w/ Gas Shock Assist Stake Pockets Outside Frame Stake Pockets Additional Stake Pockets (Each) Trailer Plug 7-Way RV Lights L.E.D. D.O.T. Stop, Tail, Turn & Clearance Wiring Grommet-Mounted Lifetime L.E.D. Lighting Tires ST235/80 R-16 Load Range E Tire Upgrade (ST235/80 R-16 LR-G) Bolt Pattern 8-Bolt Spare Mount Side Spare Tire Mount Spare Tire Spare Tire (ST235/80 R-15 LR-E) Spare Tire & Wheel (ST235/80 R-16 LR-E) Paint Type Professional Finish w/ Primer Standard Paint Color Black Red Grey White Desert Tan Jet Blue Slime Green Implement Green Equipment Orange Medium Yellow Tie-Downs 5/8″ D-Ring Sides 15″ Tall Open sides with 3″x 2”x 3/16″ Angle uprights and 3″ x 3″ Square Tubing Top Rail 2′ High Sides (Open, Total Height with Top Rail) 3’ High Sides (Open, total height with Top Rail) 4’ High Sides (Open, total height with Top Rail) Car Hauler Style (No Side Rails) Enclose Sides w/ Expanded Metal (Per Square Foot) Enclose Sides w/ Sheet Metal (Per Square Foot) Storage Bolt-On Landscape Box (24″ x 24″ x 87″) MODEL 14PI-16 PULL TYPE Bumperpull GVWR 14000 lbs GAWR (EA. AXLE) 7000 lbs EMPTY WEIGHT 2740 lbs CARGO CAPACITY 11260 lbs BED LENGTH 16′ BED WIDTH 83″ A 193-1/2″ B 115″ C 78-1/2″ TONGUE LENGTH 42-3/4″ MODEL 14PI-18 PULL TYPE Bumperpull GVWR 14000 lbs GAWR (EA. AXLE) 7000 lbs EMPTY WEIGHT 2890 lbs CARGO CAPACITY 11110 lbs BED LENGTH 18′ BED WIDTH 83″ A 217-1/2″ B 127” C 90-1/2″ TONGUE LENGTH 42-3/4″ MODEL 14PI-20 PULL TYPE Bumperpull GVWR 14000 lbs GAWR (EA. AXLE) 7000 lbs EMPTY WEIGHT 3040 lbs CARGO CAPACITY 10960 lbs BED LENGTH 20′ BED WIDTH 83″ A 240″ B 138″ C 102″ TONGUE LENGTH 42-3/4″
